Features
- Ranging from 4 – 120 Tonne capacity
- Delivered and installed ready to use
- Silos sealed gas tight complying with Australian standard AS2628
- Zincalume barrel and roofs and galvanized support structure
- All models can be custom designed to suit your specific needs
- Covered by HE Silos Gunnedah 5 year warranty
- HE Silos phosbox for safer fumigation at ground level
- Optional upgrade to white Colorbond barrels and roof to effectively reduce the temperature inside the silo, ensuring greater storage conditions
- Optional upgrade to stainless steel base
Safety features and inclusions
- Sight glasses x 2 in top and bottom barrels to indicate level of grain in silo
- Safety ladders and cages that comply with Australian Standard AS1657
- Slide ladder that lock into place above ground to prevent accessibility to children and visitors
- Pressure relief valve
- Ground opening lid
- Manhole in base
- Optional aeration and fumigation systems (please refer to our AERATION & FUMIGATION page)
Sealed, gas tight silos
Sealed silos, otherwise known as gas tight silos, are recommended for long term storage of grain.
Sealed silos are a controlled atmosphere that acts as fumigation chambers for effective control of insects at all life stages. A silo is only truly sealed if it passes a five-minute half-life pressure test according to the Australian Standard AS2628. A silo that does not meet the standard will allow gas to leak out. The concentration of fumigant will be reduced, and there is a chance of insect survival.
HE Silos Gunnedah ensures it has met and exceeded Australian Standard AS 2628 of sealed silos. This is done throughout the manufacturing process by:
- Ensuring all seams and joins are sealed both inside and out
- Rubber Seals made of high density on all openings
- Pressure relief oil valve
- Ability to pressure test your silo onsite
- Silos are pressure tested before leaving our factory
HE Silos phosbox for safer fumigation at ground level
- Optional upgrade to white Colorbond barrels and roof to effectively reduce the temperature inside the silo, ensuring greater storage conditions
Optional upgrade to stainless steel base
- Ranging from 4 – 120 Tonne capacity
- Delivered and installed ready to use
- Silos sealed gas tight complying with Australian standard AS2628
- Zincalume barrel and roofs and galvanized support structure
- All models can be custom designed to suit your specific needs
- Covered by HE Silos Gunnedah 5 year warranty
- HE Silos phosbox for safer fumigation at ground level
- Optional upgrade to white Colorbond barrels and roof to effectively reduce the temperature inside the silo, ensuring greater storage conditions
- Optional upgrade to stainless steel base
Safety features and inclusions
- Sight glasses x 2 in top and bottom barrels to indicate level of grain in silo
- Safety ladders and cages that comply with Australian Standard AS1657
- Slide ladder that lock into place above ground to prevent accessibility to children and visitors
- Pressure relief valve
- Ground opening lid
- Manhole in base
- Optional aeration and fumigation systems (please refer to our AERATION & FUMIGATION page)
Sealed, gas tight silos
Sealed silos, otherwise known as gas tight silos, are recommended for long term storage of grain.
Sealed silos are a controlled atmosphere that acts as fumigation chambers for effective control of insects at all life stages. A silo is only truly sealed if it passes a five-minute half-life pressure test according to the Australian Standard AS2628. A silo that does not meet the standard will allow gas to leak out. The concentration of fumigant will be reduced, and there is a chance of insect survival.
HE Silos Gunnedah ensures it has met and exceeded Australian Standard AS 2628 of sealed silos. This is done throughout the manufacturing process by:
- Ensuring all seams and joins are sealed both inside and out
- Rubber Seals made of high density on all openings
- Pressure relief oil valve
- Ability to pressure test your silo onsite
- Silos are pressure tested before leaving our factory
HE Silos phosbox for safer fumigation at ground level
- Optional upgrade to white Colorbond barrels and roof to effectively reduce the temperature inside the silo, ensuring greater storage conditions
Optional upgrade to stainless steel base
